PR-E-16AC-R

Expansion IO for ELC-18, ELC-22, ELC-26 and PR-18/24/26 Series – Digital (AC)

  • Power Supply: 100 – 240 VAC
  • Digital:
    • Inputs – 8-channels
      • OFF (0 – 40 VAC)
      • ON ( 85 – 240 VAC)
    • Outputs – 8-channels
      • Q1 – Q4 (Max.3A – Resistive Load Max.2A for Inductive Load)
      • Q5 – Q8 (Max.10A – Resistive Load Max.2A for Inductive Load)
  • Analogue:
    • Inputs – None
    • Outputs – None

For a lower cost alternative whilst stocks last, see our ELC-E-16AC-R.

Add to quote
SKU: PR-E-16AC-R Category: Tags: , , ,

Description

Model Voltage Digital Inputs Digital Outputs Analogue Inputs Analogue Outputs Serial
PR-E-16AC-R 110/240 VAC 8 x AC 8 x Relay - - -
PR-E-DC-16DO 12/24 VDC - 16 x Relay - - -
PR-E-DC-16IN 12/24 VDC 16 x DC - - - -
PR-E-AI-I 12/24 VDC - - 4 x 0-20mA - -
PR-RS485 12/24 VDC - - - - 1 x RS485
PR-E-AI-VI 12/24 VDC - - 4 x 0-20mA/0-10V - -
PR-E-PT100 12/24 VDC - - 3 x PT100 - -
PR-E-AQ-VI 12/24 VDC - - - 2 x 0-20mA/0-10V -
PR-E-16DC-DA-R 12/24 VDC 8 x DC (I1~I8) 8 x Relay 4 x 0-10V (I1~I4) - -
PR-E-16DC-DA-TN 12/24 VDC 8 x DC (I1~I8) 8 x PNP 4 x 0-10V (I1~I4) - -

Additional information

Weight 0.25 kg
Dimensions 80 × 95 × 70 mm
Supply

Digital Inputs

, , , ,

Digital Outputs

, ,

HS Code

COO
